0.38/0.66KV-1.9/3.3KV Coal Cutter Unscreened Or Screened Flexible Cable
APPLICATION
Coal Cutter Screened Flexible Cable is mainly applied for movable electrical equipments and coal cutter.
CABLE STANDARDS
Coal Cutter Screened Flexible Cable is manufactured according to the standards MT818.
TYPE AND NAME OF CABLE
| Type | Rated Voltage (KV) | Name | Application |
|---|---|---|---|
| MC | 0.38/0.66 | Rubber sheathed coal cutter flexible cable | For power supply of coal cutter or similar equipment of rated voltage 0.38/0.66KV |
| MCP | 0.38/0.66 | Rubber sheathed with screen coal cutter flexible cable | For power supply of coal cutter or similar equipment of rated voltage 0.38/0.66KV |
| MCP | 0.66/1.14 | Rubber sheathed with screen coal cutter flexible cable | For power supply of coal cutter or similar equipment of rated voltage 0.66/1.14KV |
| MCP | 1.9/3.3 | Rubber sheathed with screen coal cutter flexible cable | For power supply of coal cutter or similar equipment of rated voltage 1.9/3.3KV |
| Type | Rated Voltage (KV) | Nominal Cross-sectional Area of Main Core(mm²) | Number of Cores(Main Core) | Number of Cores(Earthing Core) | Number of Cores(Monitoring Core) |
|---|---|---|---|---|---|
| MC | 0.38/0.66 | 16-185 | 3 | 1 | OEM |
| MCP | 0.38/0.66 | 16-185 | 3 | 1 | OEM |
| MCP | 0.66/1.14 | 35-185 | 3 | 1 | OEM |
| MCP | 1.9/3.3 | 35-185 | 3 | 1 | OEM |
