8.7~15KV YJV32-Copper Conductor XLPE Insulated PVC Sheathed Steel Wire Armoured Power Cable
APPLICATION
YJV32-Copper Conductor XLPE Insulated Steel Wire Armoured PVC Sheathed Power Cable.
Copper XLPE SWA Armoured Cable is suitable for using in power distribution networks or fixed installations for industrial equipments with rated voltage up to and including 26/35KV.
CABLE STANDARDS
GB/T12706-2008,IEC,BS,ASTM and etc. upon request.
BASIC INFORMATION
Code Name
YJV32
Rated Voltage (Uo/U)
8.7/10KV, 8.7/15KV
Cable Structure
Copper Conductor/XLPE Insulation/Steel Wire Armoured/PVC Sheath
CONSTRUCTION
Conductor
Number of conductors:1,3
The conductors shall comply with the requirement given in IEC
Insulation
XLPE(Cross-linked Polyethylene) according to IEC
Sheath
PVC(Polyaluminium Chloride) according to IEC
Metal screen
Copper Tape Screen
Armoured Layer
Steel Wire
CHARACTERISTICS
Conductor temperature
Maximum conductor temperature in normal use: 90℃
Max.short-circuit temperature
Maximum shall not exceed 250℃(5s Max,Duration)
Installation temperature
Ambient temperature under installation shall not be below 0℃
Minimum bending radius
The bending radius of cable: (D-Diameter of cable)
For Three Core Cable————————————-≥15D
For Single Core Cable————————————-≥20D
| Nominal Cross Sectional Area (mm²) | NO. of Cores | Nominal Insulation Thickness(mm) | Approx Overall Diameter(mm) | Cable Weight Max(kg/km) |
|---|---|---|---|---|
| 25 | 1 | 4.5 | 29 | 1846 |
| 35 | 1 | 4.5 | 30 | 2026 |
| 50 | 1 | 4.5 | 31.5 | 2237 |
| 70 | 1 | 4.5 | 33 | 2520 |
| 95 | 1 | 4.5 | 34.9 | 2911 |
| 120 | 1 | 4.5 | 37.5 | 3690 |
| 150 | 1 | 4.5 | 39.1 | 4005 |
| 185 | 1 | 4.5 | 40.8 | 4402 |
| 240 | 1 | 4.5 | 43.1 | 5104 |
| 300 | 1 | 4.5 | 45.7 | 5908 |
| 400 | 1 | 4.5 | 48.9 | 6982 |
| 500 | 1 | 4.5 | 52.6 | 8287 |
| 630 | 1 | 4.5 | 56.6 | 9789 |
| 25 | 3 | 4.5 | 52.4 | 4841 |
| 35 | 3 | 4.5 | 55.7 | 5394 |
| 50 | 3 | 4.5 | 58.9 | 6107 |
| 70 | 3 | 4.5 | 62.6 | 7066 |
| 95 | 3 | 4.5 | 66.4 | 8276 |
| 120 | 3 | 4.5 | 69.9 | 9312 |
| 150 | 3 | 4.5 | 73.7 | 10636 |
| 185 | 3 | 4.5 | 77.3 | 11879 |
| 240 | 3 | 4.5 | 84.2 | 15060 |
| 300 | 3 | 4.5 | 89.5 | 17597 |
| 400 | 3 | 4.5 | 96.8 | 21109 |
| 500 | 3 | 4.5 | 104.5 | 25267 |
| 630 | 3 | 4.5 | 112.6 | 29892 |
